VACUUM PLATING AS AN OPTIMAL SURFACE TREATMENT OF MATERIALS

Vacuum plating or plating in vacuum is one of the possibilities of finishing the surface layer of products. Thin film / film coating technology for metallic and non-metallic surfaces uses metal, alloy, oxide, sulfide, haloid as the source material. They are deposited in high vacuum, where they evaporate the particles and cause them to condensate and return to the solid state. The resulting surface layer creates a perfect façade with improved mechanical and aesthetic properties. Vacuum-coated parts do not require any further modifications and provide a wide range of uses in both design and design.

Vacuum plating or plating in vacuum is one of the possibilities of finishing the surface layer of products. Thin film / film coating technology for metallic and non-metallic surfaces uses metal, alloy, oxide, sulfide, haloid as the source material. They are deposited in high vacuum, where they evaporate the particles and cause them to condensate and return to the solid state. The resulting surface layer creates a perfect façade with improved mechanical and aesthetic properties. Vacuum-coated parts do not require any further modifications and provide a wide range of uses in both design and design.

Vacuum plating or plating in vacuum is one of the possibilities of finishing the surface layer of products. Thin film / film coating technology for metallic and non-metallic surfaces uses metal, alloy, oxide, sulfide, haloid as the source material. They are deposited in high vacuum, where they evaporate the particles and cause them to condensate and return to the solid state. The resulting surface layer creates a perfect façade with improved mechanical and aesthetic properties. Vacuum-coated parts do not require any further modifications and provide a wide range of uses in both design and design.

VACUUM PLATING IN PRACTICE

The surface treatment of materials by plating under vacuum has a wide spectrum of uses. Components and components finalized by vacuum coating are used in the following industries:

The surface treatment of materials by plating under vacuum has a wide spectrum of uses. Components and components finalized by vacuum coating are used in the following industries:

The surface treatment of materials by plating under vacuum has a wide spectrum of uses. Components and components finalized by vacuum coating are used in the following industries:

Mechanical Engineering and Industry

Various small plastic parts  |  active, Passive layers of sensors - piezokeramic, resistive, magnetic and others  |  Electronic disks  |  The outer surface and the internal reflector surfaces of the battery-lamp reflectors  |  Reflective surfaces of bicycle, motorcycle and automobile reflectors  |  Electrodes and contacts of electronic components  |  Electromagnetic shielding of electrical device covers

Various small plastic parts  |  active, Passive layers of sensors - piezokeramic, resistive, magnetic and others  |  Electronic disks  |  The outer surface and the internal reflector surfaces of the battery-lamp reflectors  |  Reflective surfaces of bicycle, motorcycle and automobile reflectors  |  Electrodes and contacts of electronic components  |  Electromagnetic shielding of electrical device covers

Various small plastic parts  |  active, Passive layers of sensors - piezokeramic, resistive, magnetic and others  |  Electronic disks  |  The outer surface and the internal reflector surfaces of the battery-lamp reflectors  |  Reflective surfaces of bicycle, motorcycle and automobile reflectors  |  Electrodes and contacts of electronic components  |  Electromagnetic shielding of electrical device covers

Design

Decorative reflective layers for decorative ceramics  |  Decorative reflective layers on glass beads, MC chatons  |  Decorative signs and shapes on cover devices  |  Richly shaped components of ceiling lights

Decorative reflective layers for decorative ceramics  |  Decorative reflective layers on glass beads, MC chatons  |  Decorative signs and shapes on cover devices  |  Richly shaped components of ceiling lights

Decorative reflective layers for decorative ceramics  |  Decorative reflective layers on glass beads, MC chatons  |  Decorative signs and shapes on cover devices  |  Richly shaped components of ceiling lights

Construction:

Decorative reflective layers for sanitary tiles and glass sheets

Decorative reflective layers for sanitary tiles and glass sheets

Decorative reflective layers for sanitary tiles and glass sheets

Other

Optical layers  |  Tinting cellophane foils

Optical layers  |  Tinting cellophane foils

Optical layers  |  Tinting cellophane foils

ADVANTAGES OF VACUUM COATING OF SURFACES

Technically and practically professionally modified vacuum coatings contribute to improving and improving the technical characteristics of the final product. By omitting this process, on the other hand, it degrades its use and its durability. Vacuum plating can achieve the following product benefits in terms of protection, enhancement of properties and design:

Technically and practically professionally modified vacuum coatings contribute to improving and improving the technical characteristics of the final product. By omitting this process, on the other hand, it degrades its use and its durability. Vacuum plating can achieve the following product benefits in terms of protection, enhancement of properties and design:

Technically and practically professionally modified vacuum coatings contribute to improving and improving the technical characteristics of the final product. By omitting this process, on the other hand, it degrades its use and its durability. Vacuum plating can achieve the following product benefits in terms of protection, enhancement of properties and design:

1. Protection against mechanical damage
2. Protection against corrosion and other adverse external influences
3. Increase in end-product performance
4. Improvement of mechanical properties
5. Extension of functionality and durability
6. New uses
7. Can be applied to non-metallic materials
8. Design effect
9. Design freedom of solution
10. Raise overall product quality

1. Protection against mechanical damage
2. Protection against corrosion and other adverse external influences
3. Increase in end-product performance
4. Improvement of mechanical properties
5. Extension of functionality and durability
6. New uses
7. Can be applied to non-metallic materials
8. Design effect
9. Design freedom of solution
10. Raise overall product quality

1. Protection against mechanical damage
2. Protection against corrosion and other adverse external influences
3. Increase in end-product performance
4. Improvement of mechanical properties
5. Extension of functionality and durability
6. New uses
7. Can be applied to non-metallic materials
8. Design effect
9. Design freedom of solution
10. Raise overall product quality

HOW DOES VACUUM COATING WORK?

Vacuum plating works on the principle of evaporation of metals in high vacuum and their subsequent condensation on a cold surface. The most commonly used metals are Al, Ag, Rh, Cr, Ti, Zn, Mg, which are applied in thicknesses 1-3 μm.As this process does not immerse the product in the medium, its surface temperature does not increase or the electric current flows through it, it can be as conductive as non-conductive materials. In this way, metals, glass and also plastics can be treated.

Vacuum plating works on the principle of evaporation of metals in high vacuum and their subsequent condensation on a cold surface. The most commonly used metals are Al, Ag, Rh, Cr, Ti, Zn, Mg, which are applied in thicknesses 1-3 μm. As this process does not immerse the product in the medium, its surface temperature does not increase or the electric current flows through it, it can be as conductive as non-conductive materials. In this way, metals, glass and also plastics can be treated.

Vacuum plating works on the principle of evaporation of metals in high vacuum and their subsequent condensation on a cold surface. The most commonly used metals are Al, Ag, Rh, Cr, Ti, Zn, Mg, which are applied in thicknesses 1-3 μm. As this process does not immerse the product in the medium, its surface temperature does not increase or the electric current flows through it, it can be as conductive as non-conductive materials. In this way, metals, glass and also plastics can be treated.

TECHNOLOGICAL PROCESS OF VACUUM COATING:

Preparatory phase:

Preparatory phase:

Preparatory phase:

Plating process:

Plating process:

Plating process:

Preparing the surface of the material

Preparing the surface of the material

Preparing the surface of the material

Before inserting objects into the vacuum, it is necessary to remove all impurities and grease by grinding, polishing and degreasing.

Before inserting objects into the vacuum, it is necessary to remove all impurities and grease by grinding, polishing and degreasing.

Before inserting objects into the vacuum, it is necessary to remove all impurities and grease by grinding, polishing and degreasing.

Vacuum formation in the chamber

Vacuum formation in the chamber

Vacuum formation in the chamber

storage of components and evaporating metal

storage of components and evaporating metal

storage of components and evaporating metal

Elimination of impurities

Elimination of impurities

Elimination of impurities

by means of a high-voltage discharge

by means of a high-voltage discharge

by means of a high-voltage discharge

Evaporation of the metal

Evaporation of the metal

Evaporation of the metal

using wires, belts, powders whose evaporated particles move directly to the target substrate.

using wires, belts, powders whose evaporated particles move directly to the target substrate.

using wires, belts, powders whose evaporated particles move directly to the target substrate.

Condensation on the substrate

Condensation on the substrate

Condensation on the substrate

the condensed layer adheres and accurately copies the surface of the component.

the condensed layer adheres and accurately copies the surface of the component.

the condensed layer adheres and accurately copies the surface of the component.

ARE YOU INTERESTED IN OUR SERVICES?

Do not hesitate to contact us at any time! We will be happy to talk to you about individual solutions for specific products and we will suggest the best alternative for you or your customers.

Do not hesitate to contact us at any time! We will be happy to talk to you about individual solutions for specific products and we will suggest the best alternative for you or your customers.

Do not hesitate to contact us at any time! We will be happy to talk to you about individual solutions for specific products and we will suggest the best alternative for you or your customers.
